WKIS1030 HGVAC Intrinsically Safe Pressure Transmitter

제조사 : DAVIS
제품번호:WKIS1030HGVAC
판매가격  : 원
포인트 : 점
수량 :
  PLUS   MINUS   개
■ 회원가입을 하시면 할인된가격을 보실수 있습니다.
■ 모든가격은부가세별도 입니다.
■ 회원이 되시면 가격변동정보, 신제품, 특판제품, 기술정보등 다양한
뉴스정보를 보내드립니다.
■ 30만원미만은 택배비 3,000원(착불)입니다.
■ 카드결재시 세금계산서 발행 불가합니다.
■ 배송은 평균 2~3일정도 예상됩니다.

상세페이지를 마이피플로 보내기 - 웹용 상세페이지를 twitter로 보내기 상세페이지를 facebook으로 보내기 상세페이지를 Me2Day로 보내기

The IS-10 industrial and IS-11 non-clogging flush diaphragm pressure transmitters are designed
The IS-10 industrial and IS-11 non-clogging flush diaphragm pressure transmitters are designed for industrial pressure measurement applications where intrinsically safe ratings are required. Each transmitter undergoes extensive testing and calibration to achieve an accuracy of 0.25% full scale. State-of-the-art surface mount technology ensures that the unit is protected against vibration, shock and humidity. Each unit is temperature compensated to assure accuracy and long-term stability under severe ambient temperature variations.

The compact design features all stainless steel wetted parts and is available with a variety of electrical and process connections to meet specific installation requirements.


Features
  • Approvals pending for Class I Division 1 and Class I Zone 0 locations when used with an approved barrier
  • 4-20 mA 2-wire output signal
  • Highly resistant to pressure spikes and vibration

SPECIFICATIONS

Accuracy

 + 0.25% Best Fit Straight Line
Wetted Parts 316SS and PH17 – 4 SS (>= 400 psi)
Case 316SS
Pressure Connection 1/2" NPT Male
Power Supply 10 – 30 V DC
Signal Output 4 – 20mA, 2-wire
CAT NO. MODEL DEscRIPTION AVAIL PRICE
WKIS1030HGVAC   　 　 Intrinsically Safe Pressure Transmitter, 30-0 Inches Hg Vacuum   Yes   1,026,000
WKIS100050INWC   　 　 Intrinsically Safe Pressure Transmitter, 0-50 Inches Water Column   Yes   853,200　
WKIS100100INWC   　 　 Intrinsically Safe Pressure Transmitter, 0-100 Inches Water Column   Yes   853,200　
WKIS1000005PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 5 psi   Yes   853,200　
WKIS1000010PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 10 psi   Yes   853,200　
WKIS1000015PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 15 psi   Yes   853,200　
WKIS1000025PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 25 psi   Yes   853,200　
WKIS1000030PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 30 psi   Yes   853,200　
WKIS1000050PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 50 psi   Yes   853,200　
WKIS1000060PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 60 psi   Yes   853,200　
WKIS1000100PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 100 psi   Yes   853,200　
WKIS1000160PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 160 psi   Yes   853,200　
WKIS1000200PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 200 psi   Yes   853,200　
WKIS1000250PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 250 psi   Yes   853,200
WKIS1025000PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 25000 psi   Yes   2,581,200
WKIS1040000PSI   　 　 Intrinsically Safe Pressure Transmitter, 0 - 40000 psi   Yes   2,581,200
WKIS1000015PSIA   　 　 Intrinsically Safe Pressure Transmitter, 0 - 15 psi absolute   Yes   1,026,000　
WKIS1000025PSIA   　 　 Intrinsically Safe Pressure Transmitter, 0 - 25 psi absolute   Yes   1,026,000
WKIS1000050PSIA   　 　 Intrinsically Safe Pressure Transmitter, 0 - 50 psi absolute   Yes   1,026,000　
