Type
70
|
- High
flow capacity - Up to 80 SCFM
- Responds
quickly to minute changes in downstream pressure
- Dampening
action of aspirator tube helps maintain downstream pressure
- Balanced
supply valve minimizes the effect of supply pressure changes
- Stack
up construction can be disassembled and serviced without
removal from air line
|
| |
|
Type
50
|
- Superior
regulation characteristics
- Rugged,
corrosion-resistant construction
- Self-relieving
- Integral,
40 micron, self cleaning filter
- Several
mounting options
- Low
cost
|
| |
|
|
Type
51FR
|
- Excellent
regulation, stability and repeatability
- Corrosion-resistant
construction (no brass components)
- Low
cost
- Small
package size
- Panel,
bracket or pipe mounting
|
| |
|
| CAT
NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| MB960067 |
|
960-067-000 |
|
Type 50
Filter Regulator, General Purpose Air Filter Pipe, Panel or Bracket
Mount, 0-30 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960068 |
|
960-068-000 |
|
Type 50
Filter Regulator, General Purpose Air Filter Pipe, Panel or Bracket
Mount, 0-60 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960069 |
|
960-069-000 |
|
Type 50
Filter Regulator, General Purpose Air Filter Pipe, Panel or Bracket
Mount, 0-120 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960175 |
|
960-175-000 |
|
Type 51FR
Filter Regulator, Compact, Low Cost, Air Filter Regulator Pipe, Panel or
Bracket Mount, 0-30 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960176 |
|
960-176-000 |
|
Type 51FR
Filter Regulator, Compact, Low Cost, Air Filter Regulator Pipe, Panel or
Bracket Mount, 0-60 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960177 |
|
960-177-000 |
|
Type 51FR
Filter Regulator, Compact, Low Cost, Air Filter Regulator Pipe, Panel or
Bracket Mount, 0-100 psig, 40 Micron Filter |
|
Yes |
|
127,440
|
| MB960129 |
|
960-129-000 |
|
Type 70 Air
Regulator, Precision, High Flow Air Regulator, Pipe, Panel or Bracket
Mount, 0-2 psig |
|
Yes |
|
183,600
|
| MB960130 |
|
960-130-000 |
|
Type 70 Air
Regulator, Precision, High Flow Air Regulator Pipe, Panel or Bracket
Mount, 0-10 psig |
|
Yes |
|
162,000
|
| MB960090 |
|
960-090-000 |
|
Type 70 Air
Regulator, Precision, High Flow Air Regulator Pipe, Panel or Bracket
Mount, 0-30 psig |
|
Yes |
|
162,000
|
| MB960092 |
|
960-092-000 |
|
Type 70 Air
Regulator, Precision, High Flow Air Regulator Pipe, Panel or Bracket
Mount, 1-60 psig |
|
Yes |
|
162,000
|
| MB960094 |
|
960-094-000 |
|
Type 70 Air
Regulator, Precision, High Flow Air Regulator Pipe, Panel or Bracket
Mount, 2-150 psig |
|
Yes |
|
162,000
|
| |
