AE211721 Clamp-on Meter
|
| Models 501, 502 & 503 are compact in size and measure to 400A and 600V |
|
500 Series |
- Models 501, 502 & 503 are compact in size and measure to 400A and 600V
- Models 511, 512 & 514 are standard size clamp-ons and measure to 1000A and 1000V
- Full functions: Aac, Adc, Vac, Vdc, Ohms, Continuity with beeper, Frequency, Diode Test and Hold or 1ms Peak
- Several models offer DC Amp measurements for non-linear applications
- Large easy-to-read 4000-count display
|
| |
|
F1N & F3N |
- True RMS AC Current measurements to 700A
- Frequency measurements to 10kHz
- Stores Min/Max and Avg for Current or Frequency for up to 24 hours (Model F3N)
- Fast Peak measurement (including a Max Peak) for Crest Factor in Harmonics (Model F3N)
- Smooth Function for 3 second running averages in Current and Frequency (Model F3N)
- Digital display with fast analog bargraph to show surge current
- Display Current and Frequency simultaneously
- Auto and manual ranging modes
- Tapered jaws handle two 500MCM cables or one 1.5" (38mm) cable
- Audible beep confirms key functions and new Min/Max values
- Battery life indication displayed at power-up
- Sleep mode to conserve battery life
- IEC 1010, 600V, Cat. III and agency approvals
- Supplied with soft protective carrying holster
|
| | | SPECIFICATIONS
|
Catalog No. |
AE211721 |
AE211766 |
AE211722 |
AE211767 |
| Type |
AC |
AC TRMS |
AC/DC |
AC |
| AC Current |
0.05 to 400A |
0.05 to 400A |
0.05 to 400A |
0.05 to 1000A |
| AC Voltage |
0.5 to 600V |
0.5 to 600V |
0.5 to 600V |
0.5 to 750V |
| DC Current |
— |
— |
0.10 to 400A |
— |
| DC Voltage |
0.2 to 600V |
0.2 to 600V |
0.2 to 600V |
0.2 to 1000V |
| Resistance (Ω) |
400Ω |
400Ω |
400Ω |
4000Ω |
| Continuity |
<40Ω |
<40Ω |
<40Ω |
<40Ω |
|
Frequency (Hz)
Current |
20Hz to 10kHz |
20Hz to 10kHz |
— |
1Hz to 4kHz |
| Voltage |
2Hz to 400kHz |
2Hz to 400kHz |
— |
1Hz to 10kHz |
| True RMS |
— |
Yes |
— |
— |
| Jaw Size |
1.1" (28mm) |
1.1" (28mm) |
1.1" (28mm) |
1.58" (40mm) |
| Dimension |
7.60 x 1.97 x 1.1" |
7.60 x 1.97 x 1.1" |
7.60 x 1.97 x 1.1" |
9.53 x 2.60 x 1.42" |
SPECIFICATIONS
|
Catalog No. |
AE211768 |
AE211770 |
AE120701 |
AE120703 |
| Type |
AC TRMS |
AC/DC TRMS |
AC TRMS |
AC TRMS |
| AC Current |
0.05 to 1000A |
0.05 to 1000A |
0.3 to 400A |
0.3 to 400A |
| AC Voltage |
0.5 to 750V |
0.5 to 750V |
— |
— |
| DC Current |
— |
1A to 1000A |
— |
— |
| DC Voltage |
0.2 to 1000V |
0.2 to 1000V |
— |
— |
| Resistance (Ω) |
4000Ω |
4000Ω |
— |
— |
| Continuity |
<40Ω |
<40Ω |
— |
— |
Frequency (Hz)
Current |
1Hz to 4kHz |
1Hz to 4kHz |
0.5 to 10kHz |
0.5 to 10kHz |
| Voltage |
1Hz to 10kHz |
1Hz to 10kHz |
— |
— |
| True RMS |
Yes |
Yes |
Yes |
Yes |
| Jaw Size |
1.58" (40mm) |
1.58" (40mm) |
1.575" (40mm) |
1.575" (40mm) |
| Dimension |
9.53 x 2.60 x 1.42" |
9.53 x 2.60 x 1.42" |
9.11 x 3.82 x 1.73" |
9.11 x 3.82 x 1.73" |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| AE211721 |
|
501 |
|
Clamp-on Meter Model 501, 400Aac, 600Vac/dc, Ohms, Continuity, Hz |
|
Yes |
|
213,840 |
| AE211766 |
|
502 |
|
Clamp-on Meter Model 502, TRMS, 400Aac, 600Vac/dc, Ohms, Continuity, Hz |
|
Yes |
|
300,240
|
| AE211722 |
|
503 |
|
Clamp-on Meter Model 503, 400Aac/dc, 600Vac/dc, Ohms, Continuity |
|
Yes |
|
365,040
|
| AE3390111 |
|
511 |
|
Clamp-on Meter Model 511, 1000Aac, 600Vac/dc, Ohms, Continuity, Hz |
|
Yes |
|
300,240 |
| AE211768 |
|
512 |
|
Clamp-on Meter Model 512, TRMS, 1000Aac, 600Vac/dc, Ohms, Continuity, Hz |
|
Yes |
|
386,640
|
| AE211770 |
|
514 |
|
Clamp-on Meter Model 514, TRMS, 1000Aac/dc, 600Vac/dc, Ohms, Continuity, Hz |
|
Yes |
|
429,840
|
| AE120701 |
|
F1N |
|
AC Clamp-On Meter Model F1N (TRMS, 400A, Hz) |
|
Yes |
|
421,200 |
| AE120703 |
|
F3N |
|
AC Clamp-On Meter Model F3N TRMS, 400A, Hz, Peak, Smooth, Min/Max) |
|
Yes |
|
537,840
| | |
