SE37000 AC to DC Current Transducer

제조사 : DAVIS
제품번호:SE37000
시중가격 : 원
판매가격  : 원
포인트 : 점
수량 :
  PLUS   MINUS   개
■ 회원가입을 하시면 할인된가격을 보실수 있습니다.
■ 모든가격은부가세별도 입니다.
■ 회원이 되시면 가격변동정보, 신제품, 특판제품, 기술정보등 다양한
뉴스정보를 보내드립니다.
■ 30만원미만은 택배비 3,000원(착불)입니다.
■ 카드결재시 세금계산서 발행 불가합니다.
■ 배송은 평균 2~3일정도 예상됩니다.

상세페이지를 마이피플로 보내기 - 웹용 상세페이지를 twitter로 보내기 상세페이지를 facebook으로 보내기 상세페이지를 Me2Day로 보내기

Use with Simpson digital DC process indicators, 24VDC power required
Current Transducers
  • Use with Simpson digital DC process indicators
  • 24VDC power required
  • Reduces high AC current signal to 4-20mA DC signal
  • Accuracy +/- 0.5% F.S.

AC Current Transformers
  • Use with Simpson analog panel instruments and 5AAC digital indicators requiring external current transformers
  • Donut-type are inserted one turn primary and include 2 ft. leads
  • Reduces high AC current signal to 5AAC output to meter

CAT NO MODEL DEscRIPTION AVAIL PRICE
SE37000   37000   AC to DC Current Transducer, 5A/4-20mA   Yes   490,536
SE37001   37001   AC to DC Current Transducer, 50A/4-20mA   Yes   1,513,728
SE37002   37002   AC to DC Current Transducer, 75A/4-20mA   Yes   579,312
SE37003   37003   AC to DC Current Transducer, 100A/4-20mA   Yes   579,312
SE37004   37004   AC to DC Current Transducer, 150A/4-20mA   Yes   605,880
SE37005   37005   AC to DC Current Transducer, 200A/4-20mA   Yes   605,880
SE37006   37006   AC to DC Current Transducer, 300A/4-20mA   Yes   639,576
SE01293   01293   Donut AC Current Transformer, 50/5 Amps   Yes   66,312
SE01306   01306   Donut AC Current Transformer, 75/5 Amps   Yes   69,768
SE01297   01297   Donut AC Current Transformer, 100/5 Amps   Yes   68,472
SE01298   01298   Donut AC Current Transformer, 150/5 Amps   Yes   68,472
SE01299   01299   Donut AC Current Transformer, 200/5 Amps   Yes   68,472
SE01300   01300   Donut AC Current Transformer, 300/5 Amps   Yes   68,472
SE01301   01301   Donut AC Current Transformer, 500/5 Amps   Yes   68,472
SE02303   02303   Donut AC Current Transformer, 600/5 Amps   Yes   68,472
