LM700 Single Phase Color Backlit

제조사 : DAVIS
제품번호:LM700
시중가격 : 원
판매가격  : 원
포인트 : 점
수량 :
  PLUS   MINUS   개
■ 회원가입을 하시면 할인된가격을 보실수 있습니다.
■ 모든가격은부가세별도 입니다.
■ 회원이 되시면 가격변동정보, 신제품, 특판제품, 기술정보등 다양한
뉴스정보를 보내드립니다.
■ 30만원미만은 택배비 3,000원(착불)입니다.
■ 카드결재시 세금계산서 발행 불가합니다.
■ 배송은 평균 2~3일정도 예상됩니다.

상세페이지를 마이피플로 보내기 - 웹용 상세페이지를 twitter로 보내기 상세페이지를 facebook으로 보내기 상세페이지를 Me2Day로 보내기

Photo quality backlit colour display for oscilloscope mode, spectrum mode and multi parameter display
The Power Quality industries’ leading software

Allows the viewer to scroll through event, timeline and waveform data simultaneously, zero in on captured disturbance waveforms, scan historical trends, evaluate static’s and perform harmonic and interharmonic analysis-all with the click of a mouse. With it’s intuitive two-pane browser, complete report writing capabilities, Windows® interface and simple-to-use visualization and analytical capabilities, this software turns every user into a power quality expert.

Features
  • Photo quality backlit colour display for oscilloscope mode, spectrum mode and multi parameter display
  • Unique power quality overview mode on a single screen for fast and efficient troubleshooting
  • AC voltage and current (via flexible CT up to 3000A)
  • Additional current probes available for low current measurement
  • mV/A input for installed current transformers
  • W, VA, VAR, kWHr and Power Factor measurement, even for distorted waveforms
  • Built in 3 phase power capability for balanced loads
  • TRMS, Peak, Crest Factor, THD, DF and Frequency for current and voltage
  • Harmonics to the 50th with magnitude and phase information
  • Measurement of dips, sags, swells, flicker
  • Inrush current measurement
  • Record function for MIN, MAX and Average
  • Internal datalogging and full power quality surveying with time and date stamped values
  • Reporting to EN50160 power quality standard with customized parameters

SPECIFICATIONS
Nominal Voltage Delta: 200/400/830V
Star: 115/230/480V
Intrinsic Error 115V - 830V – 0.2%; Resolution 0.1V
Current Ranges 30/300/3000A ; Intrinsic Error 0.5% (excludes probe); Resolution 0.01A
Power Intrinsic Error 1%; Resolution 1W
Frequency Range 45-65Hz; Intrinsic Error 0.2%; Resolution 0.01Hz
Harmonics 1st-50th Vrms, Irms, THD V, THD I
Events ntrinsic Error 1%; Flicker FL, Pst, Plt, IEC 1000-4-15; Intrinsic Error 3%

CAT NO. MODEL DEscRIPTION AVAIL PRICE
LM700   Analyst Q70   Single Phase Color Backlit Graphical Power Quality Instrument   Yes   4,571,640
1, 30/300/3000A LEMflex flexible CT, Dran-View® software, carrying case
