Professional data logger for humidity and temp.
with ext. probe socket
 |
Sensitive products require the right ambient
conditions during production and storage. Efficient measurement and documentation
of the readings over months/years is possible with the testo 177-H1 professional
data logger.
Additional surface, immersion and air
probes can be attached to the data logger e.g. for uninterrupted measurement
of the
dew point distance.
● Long-term stable humidity sensor with fast
response time
● Control and adjustment option with
adjustment set
● Protective caps for dirt-ingressed
air or corrosive gases
● Convenient documentation with infrared
printer or PC/notebook
| testo 177-H1 |
Intern. %RH, °C, °C td
+ extern. °C
testo 177-H1, humidity/temperature logger, 4 channels, with internal
sensors and additional external temperature probe socket, wall holder
and calibration protocol
Part no. 0563 1775 958,000
원 |
|
Efficient measurement of production and storage ambient conditions, to assure
stable quality
Collect data on-site with the testo 580 data collector, download and analyse
on PC/Notebook. |
| Suitable probes at a glance |
 |
| Part
no. |
0628
7510
84,000 원 |
| 0628
7503* |
| 0610
1725* |
| 0628
7514* |
| 0628
7516* |
0628
7507
127,000 원 |
0613
4611
168,000 원 |
| 0613
2211* |
| 0613
2411* |
| 0613
3211* |
| 0613
1711* |
|
 |
 |
◈The specified seal class of the
data loggers is achieved with these probes.
* Probe tested to EN 12830 for suitability in the transport and storage
sectors |
Practical accessories and recommended sets
Wall holder, for quick attachment of logger to wall
Included
Lock for wall holder
Part no. 0554 1755 18,000
원 |
testo 575 fast printer, incl. 1 roll of thermal paper and batteries
Part no. 0554 1775 780,000
원
|
| testo 177-H1, Standard Set
for logging ambient air conditions |
 |
testo 177-H1, humidity/temperature
logger, 4 channels, wall holder and calibration protocol
Lock for wall holder
testo 575 fast printer
ComSoft 3 - Basic Set for testo 177, Basic software incl. interface,
desk-top holder, PC connection cable |
|
testo 580 data collector including readout holders
Part no. 0554 1778 430,000 원 |
ComSoft 3 - Basic Set for testo
177, Basic software
Part no. 0554 1774 166,000 원 |
| testo 177-H1, Professional
Set for dew point difference measurement |
 |
testo 177-H1, humidity/temperature
logger, 4 channels, wall holder and calibration protocol
Lock for wall holder
Wall surface temperature probe
testo 575 fast printer
ComSoft 3 - Professional with data management
Interface incl. desk-top holder, PC connection cable |
|
| Ordering data
for Accessories |
Part
no. |
testo 575 fast printer, incl. 1 roll of thermal paper
and batteries
Infrared thermal line printer with graph function |
0554 1775
780,000 원 |
| Spare thermal paper for printer (6 rolls) |
0554 0569
38,000 원 |
Spare thermal paper for printer (6 rolls)
Measurement data documentation legible for up to 10 years |
0554 0568
43,000 원 |
| Label thermal paper (Testo patent) for testo 575
printer (6 rolls), can be applied directly |
0554 0561
72,000 원 |
| testo 580 data collector including readout holders
for testo 175/177 data loggers |
0554 1778
430,000 원 |
ComSoft 3 - Basic Set for testo 177, Basic software
With diagram and table function, interface incl. desk-top holder,
PC connection cable |
0554
1774
166,000 원 |
ComSoft 3 - Professional with data management
Incl. database, analysis and graphics function, data analysis, trend
curve (without interface) |
0554 0830
617,000 원 |
※ComSoft 3 - For requirements in accordance with
CFR 21 Part 11
Incl. database, analysis and graphics function, data analysis, trend
curve |
0554 0821
2,805,000 원 |
| Interface for testo 175/177 incl. desk-top holders,
PC connection cable(please also order for ComSoft 3 - Professional) |
0554 1757
149,000 원 |
| Lock for wall holder for testo 175/177 data loggers |
0554 1755
18,000 원 |
| Battery, 3.6 V/1.9 Ah 1AA |
0515 0177
67,000 원 |
| Transport case for up to 5 testo 177 data loggers,
testo 575 printer, testo 580 data collector and accessories |
0516 1770
161,000 원 |
| Metal protection cage, Ø 12 mm for humidity probes
For velocities of less than 10 m/s |
0554 0755
77,000 원 |
| Cap with wire mesh filter, Ø 12 mm |
0554 0757
99,000 원 |
| Teflon sintered filter, Ø 12 mm, for corrosive substances
High humidity range (long-term measurements), high velocities |
0554 0756
79,000 원 |
Stainless steel sintered cap, Ø 12 mm, is screwed
onto humidity probe
For measurements at high velocity speeds or in dirt ingressed air |
0554 0647
67,000 원 |
| Control and humidity adjustment set 11.3%RH/75.3%RH
incl. adapter for humidity probes |
0554 0660
487,000 원 |
ISO calibration certificate/Humidity
Humidity data logger; calibration points 11.3%RH and 75.3%RH
at +25°C; per channel/instrument |
0520 0076
268,000 원 |
DKD calibration certificate/Humidity
Humidity data logger; cal. points 11.3%RH and 75.3%RH at
+25°C; per channel/instrument |
0520 0246
689,000 원 |
ISO calibration certificate/Temperature
Temperature data logger; calibration points -18°C; 0°C; +60°C
per chan./instr. |
0520 0151
230,000 원 |
|
| Technical data |
| Chann. intern |
3 |
| Meas. range |
0... +100 %RH -20... +70 °C -40... +70 °C td |
Accuracy
± 1 digit |
±2 %RH (0... +100 %RH)
±0.5 °C (-20... +70 °C) |
| Resolution |
0.1 %RH (0... +100 %RH) 0.1 °C (-20... +70
°C)
0.1% of mv (-40... +70 °C td) |
|
|
| Memory |
48000 |
| Oper. temp. |
-20... +70 °C |
| Storage temp. |
-40... +85 °C |
| Battery type |
Lithium battery |
| Weight |
130 g |
| Dimensions |
103x64x33 mm |
| Warranty |
2 years |
Battery life: 5 years with a measuring
cycle of 15min (-10 to +50°C)
Measuring cycle: 2 s to 24h
Software: Microsoft Windows 95b / 98 /ME / NT4-Sp4 / 2000 /
XP |
|
| Chann. external (var.) 1 |
| Meas. range |
-40... +120 °C |
Accuracy
± 1 digit |
±0.2 °C (-25... +70 °C)
±0.4 °C (-40... -25.1 °C)
±0.4 °C (+70.1... +120 °C) |
| Resolution |
0.1 °C (-40... +120 °C) |
|
|
| |
