30일간의 최대, 최소 기록 가능 무선으로 열전사 적외선 프린터에서 데이터 출력 가능 (printer HP82240B)
30일간의 최대, 최소 기록 가능 또는 실시간 데이터를 최후 128개 까지 프린트 가능
Wireless report to portable thermal printer HP82240B
전원 공급
내장 Lithium battery 3.6V, 1/2AA, 1.2AH
Battery 수명
약 24개월 (연결된 센서의 숫자 와 샘플링 속도의 설정치에 따라 변수가 있음)
규격
72mm 직경, 22.9mm 두께
무게
55g
55g
를
MicroLab MicroLab 소프트웨어
MicroLab 특징:
전체 데이터 분석
MicroLog 로 부터 데이터 수집
자동으로 일별 자료 수집
그래프 및 테이블 표시
MicroLog 표시기 당 경보레벨
MicroLog 설정 기능
Sensor 단위 설정
각 data logger 에 명령
자동 데이터 저장
여러가지 보고서 형식으로 일별 상태 보고
MicroLab 와 MicroLabPLUS software 로 새로운 데이터 특징 분석 가능.
이 기능들은 현장의 다양한 요구에 맞추어 개발된 기능으로 신제품인 MicroLogPRO, new 10bit datalogger 와 같이 사용이 가능하다.최대, 최소 , 평균 수치 등의 통계 자료 분석 기능과 사용 환경 및 자료 저장 기간 동안의 측정 자료 요약 내용을 간결하게 볼 수 있으며 이 기능은 특히 의약품 제조 유통 과정에서 아주 유효 하다.
Mean Kinetic Temperature (동적 온도): 저장, 이송, 분배 과정에서 각기 다른 온도에서 누적된 열 스트레스의 표시.
Pasteurization (살균) : 식품 제조 공정에서 살균 처리 분석 에는 : High Temperature Short Time (HTST) 고온 단시간 살균; Ultra Pasteurization (UP) 울트라 살균 and Ultra High Temperature (UHT) 울트라 고온 살균.
Histogram (히스토그램): 측정 시간 과 퍼센트 레벨을 정의된 파라미터에 따라 표시한 역사적 데이터 측정 결과를 그래프로 보는 것으로 예를 들면 박물관 등에서 일정한 기간 동안 습도 측정 결과를 보고 관리하는 용도
데이터는 명확히 구분하여 로거의 ID 번호 별로 관리 하며 MicroLab 소프트웨어는 데이터를 자동으로 저장하여 일별로 환경 보고서를 만든다.
일별 저장 파일 관리: 일반적으로 사용하는 방법 대신 2번째 방법을 개발함. 이 방법은 데이터를 24시간 간격으로 나누어 각 단위별로 저장하여 향후 외부 표준에 맞는 통합 보고서를 만드는데 사용이 가능하다.
Text 기록 : enables text marks to be placed on the graph at relevant points where certain information needs to be highlighted.
Data 기록은 당신이 원하는 스프레드 쉬트 로 이송이 가능하다 (MicroLog 2 Excel software 이용).
GMT 기록 설정된 데이터 시간 기록은 GMT (Greenwich Mean Time) 로 하여 기록이 가능하여 특히 수출입 업체용에 요긴하다.
MicroLabPLUS MicroLabPLUS 소프트웨어
MicroLabPLUS 특징:
무선 통신으로 최대 200개의 MicroLogs 와 연결
실시간 다중 파라미터 센서로 데이터 읽기 가능
데이터 표시는 meters 또는 graphs
데이터가 설정치 를 넘을 시에 시각 및 음성 경보
Email 과 휴대폰으로 전달
Battery 레벨 표시
자동 데이터 저장 과 Excel 에 자료 이송
MicroLog 설정 기능:
Sensor 정의
Sensor 교정
크래들 별 ID 번호
경보 레벨 과 로거 정보
각 로거에 명령
Sampling 속도: 매 10 초 ~ 2 시간
New data analysis features for both MicroLab and MicroLabPLUS software.
These features respond specifically to requests from the field that enable a broader and more complex range of application environments. Not only do both versions now support the MicroLogPRO, new 10bit datalogger but provide analysis functionality including statistics – maximum, minimum and average enabling a quick glance summary of the environment and historical analysis. This is usually used by pharmaceutical companies who need a constant bird's eye picture of the conditions their materials are kept in.
Mean kinetic temperature, an expression of cumulative thermal stress in different temperatures during storage, transportation and distribution.
Pasteurization provides analysis for the most common methods of pasteurization in Industry: High Temperature Short Time (HTST); Ultra Pasteurization (UP) and Ultra High Temperature (UHT) pasteurization.
Histogram provides a graphical view of historical results presented according to defined parameters of periods of time and percentage levels. This provides a level of analysis which can be tailored to specific environment needs for an immediate picture. For example this can be used in a museum environment where the percentage of time the humidity reached certain levels can be viewed.
A screen shot of the actual working environment indicates pictorially where the sensors are placed and allows for immediate alert identification and resolution. Data can be clearly identified according to the ID number of the logger it came from and the threshold relevant to the that logger.
MicroLabPLUS lost communication alarm: Added alarm features for lost communication, indicates when the signal has been lost, when communication has been regained and when the battery is low.
Cradle activation and deactivation transmission means that the user can select which cradles from his entire environment he wishes to view and record at any given moment. Cradle activation and deactivation transmission means that the user can select which cradles from his entire environment he wishes to view and record at any given moment.
Selection of historic files according to sampling and average rates. On opening any given file the software automatically provides the option to select a specific data transmission time period and sampling rate.
MicroLog / MicroLogPLUS External Sensors
MicroLog 용 외부 센서 종류:
DT132 (2.5m) 외부 온도 센서
This MicroLog sensor takes external temperature measurements in a wider range than the internal temperature sensor. With a faster response time than the internal sensor, it enables measuring materials that cannot be measured with the internal sensor.
사양:
Range:
-50°C to 100°C
Resolution:
Better than 2°C
Accuracy:
±2% of reading
Probe Length:
100 mm
Probe OD
3.2 mm
Max. temperature
150°C
DT093 외부 온도 센서 (8m Probe 케미블)
Range:
-50°C to 100°C
Resolution:
Better than 2°C
Accuracy:
±2% of reading
Probe Lenght:
8m
Probe OD:
3.2mm
Max. Temperature:
100°C
DT140 0-10 전압 센서
A general sensor that will measure any device or transmitter that produces a linear analog 0-10V output. The voltage can easily be converted to the correct measured units with the help of the Microlab program.
Specifications:
Range:
0-10V
Resolution:
0.05V
Accuracy:
±3% before calibration
Input Impedance:
3 M
Calibration:
Two point calibration
OV protection:
+30V
DT139 0-20 mA 외부 전류 센서
This MicroLog external sensor can sample any device or transmitter, producing a linear current between 0-20 mAmp. The 0-20 mAmp can be converted to the correct measured units by using Microlab¹s calibration option.
Specifications:
Range:
0-20 mA
Resolution:
±0.1 mA
Accuracy:
±3 before calibration
Calibration:
Two point calibration
OC protection:
55 mA
DT141 외부 접점 어뎁터
This MicroLog sensor monitors Reed Relay contacts and switch status (open/closed), to identify the correlation between phenomena such as temperature change and door status.
Specifications:
Range:
open/close
Connector:
Screw Terminal
Cable Length:
2.5 m
Internal Pull-Up Resistor:
No need for external power source
DT168 외부 pH Adaptor
Range:
0-14 pH
Resolution:
0.116 pH
Accuracy:
5% of reading
Calibration:
Offset calibration
외부 PT100 온도 Adaptor
Range:
-10°C to 10°C / -100°C to 120°C
Resolution:
0.1°C / 1.1C
Accuracy:
±0.25°C / ±1°C
Connector:
Screw Terminal
DT279 전도도 Adapter and Electrode
Range:
0 – 20mS
Resolution:
0.04mS
Accuracy:
3%
Response time:
less than 1 minute
DT163 Light (광도)
Light Range:
0 - 5000 Lux
Resolution:
25 Lux
Accuracy:
20% of reading
DT288 토양 수분계
Range:
0-100%
MicroLogPRO MicroLogPRO Sensors
Built-in sensors:
Temperature
Range:
-40°C to 80°C
Resolution:
Better than 2°C
Accuracy:
±2% of reading
Humidity
Range:
0 – 100%
Resolution:
0.1%
Accuracy:
3%
External sensors:
LCD units icons: ˚C, ˚F, %RH, pH, V, mA, mS
Temperature
Range:
-540°C to 110°C
Resolution:
Better than 0.3°C
Accuracy:
1°C
Voltage
Range:
0 to 10V
Resolution:
0.01V
Accuracy:
1.5°C
Current
Range:
0 to 20 mA
Resolution:
0.02mA
Accuracy:
1.5°C
pH
Range:
1 to 14 pH
Resolution:
0.02pH
Accuracy:
2%
Conductivity
Range:
0 to 20mS
Resolution:
0.04mS
Accuracy:
3%
