| Optional plug in
cards for Base Panel Meters (up to 3 cards, one of each different type) |
| |
|
Features
(model dependant)
|
- Universal
AC and DC power models
- User
programmable inputs and buttons
- PC
software programmable
- 9 digit
totalizer
- 20
readings per second
- 16
point linearizer
- Selectable
built-in excitation
- Minimum
and maximum memory capture
- Optional
custom units overlay with backlight
- NEMA 4X
/ IP65 Front
- UL, CUL,
and CE Approved
|
| |
|
| CAT
NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| RLPAXD0000 |
|
PAXD |
|
1/8 DIN
Universal DC Panel Meter |
|
Yes |
|
516,240
|
| INPUTS:
DC Voltage 200mV, 2V, 20V, 300V, DC Current 200uA, 2mA, 20mA, 200mA, 2A
- POWER: 85-250VAC |
| RLPAXD0010 |
|
PAXD |
|
1/8 DIN
Universal DC Panel Meter |
|
Yes |
|
572,400
|
| INPUTS:
DC Voltage 200mV, 2V, 20V, 300V, DC Current 200uA, 2mA, 20mA, 200mA, 2A
- POWER: 11-36VDC/24VAC |
| RLPAXP0000 |
|
PAXP |
|
1/8 DIN
Process Input Panel Meter |
|
Yes |
|
494,640
|
| INPUTS:
0 to 20mA, 0 to 10V DC - POWER: 85-250VAC |
| RLPAXP0010 |
|
PAXP |
|
1/8 DIN
Process Input Panel Meter |
|
Yes |
|
550,800
|
| INPUTS:
0 to 20mA, 0 to 10V DC - POWER: 11-36VDC/24VAC |
| RLPAXT0000 |
|
PAXT |
|
1/8 DIN
Temperature Panel Meter |
|
Yes |
|
494,640
|
| INPUTS:
Thermocouples- T, E, J, K, R, S, B, N, C, RTDs- 100 Ohm Platinum
385/392, 120 Ohm, Nickel 672, 10 Ohm Copper 427 - POWER: 85-250VAC |
| RLPAXT0010 |
|
PAXT |
|
1/8 DIN
Temperature Panel Meter |
|
Yes |
|
550,800
|
| INPUTS:
Thermocouples- T, E, J, K, R, S, B, N, C, RTDs- 100 Ohm Platinum
385/392, 120 Ohm, Nickel 672, 10 Ohm Copper 427 - POWER: 11-36VDC/24VAC |
| RLPAXS0000 |
|
PAXS |
|
1/8 DIN
Strain Gage / Load Cell Panel Meter |
|
Yes |
|
732,240
|
| INPUTS:
24mV Differential, 240mV Differential - POWER: 85-250VAC |
| RLPAXS0010 |
|
PAXS |
|
1/8 DIN
Strain Gage / Load Cell Panel Meter |
|
Yes |
|
788,400
|
| INPUTS:
24mV Differential, 240mV Differential - POWER: 11-36VDC/24VAC |
| RLPAXH0000 |
|
PAXH |
|
1/8 DIN True
RMS AC Voltage / Current Panel Meter |
|
Yes |
|
645,840
|
| INPUTS:
AC Voltage 200mV, 2V, 85-250VAC, Current 200uA, 2mA, 200mA, 5A - POWER:
20V, 300VAC |
| RLPAXI0000 |
|
PAXI |
|
1/8 DIN
Counter / Rate Panel Meter |
|
Yes |
|
537,840
|
| INPUTS:
To 34kHz Max (rate only), Consult Max Freq Table for Application Specs -
POWER: 85-250VAC |
| RLPAXI0010 |
|
PAXI |
|
1/8 DIN
Counter / Rate Panel Meter |
|
Yes |
|
594,000
|
| INPUTS:
To 34kHz Max (rate only), Consult Max Freq Table for Application Specs -
POWER: 11-36VDC/24VAC |
| RLPAXCDS10 |
|
PAXCDS |
|
Plug-In
Output Card, Dual Setpoint Relay Output Card |
|
Yes |
|
75,600
|
| RLPAXCDS20 |
|
PAXCDS |
|
Plug-In
Output Card, Quad Setpoint Relay Output Card |
|
Yes |
|
97,200
|
| RLPAXCDS30 |
|
PAXCDS |
|
Plug-In
Output Card, Quad Setpoint Sinking Open Collector (NPN) Output Card |
|
Yes |
|
75,600
|
| RLPAXCDS40 |
|
PAXCDS |
|
Plug-In
Output Card, Quad Setpoint Sourcing Open Collector (PNP) Output Card |
|
Yes |
|
75,600
|
| RLPAXCDC10 |
|
PAXCDC |
|
Plug-In
Communications Card, RS485 Serial Communications Card |
|
Yes |
|
97,200
|
| RLPAXCDC20 |
|
PAXCDC |
|
Plug-In
Communications Card, RS232 Serial Communications Card |
|
Yes |
|
97,200
|
| RLPAXCDC30 |
|
PAXCDC |
|
Plug-In
Communications Card, DeviceNet Communications Card |
|
Yes |
|
151,200
|
| RLPAXCDC40 |
|
PAXCDC |
|
Plug-In
Communications Card, MODBUS Communications Card |
|
Yes |
|
118,800
|
| RLPAXCDL10 |
|
PAXCDL |
|
Plug-In
Process Output Card, (0-10VDC or 4-20mA) Analog Output Card |
|
Yes |
|
151,200
|
| RLSFPAX |
|
SFPAX |
|
OPTIONAL
Windows Configuration Software for PAX
Meters (3.5" disk) FOR Intelligent Panel
Meters |
|
Yes |
|
62,640
|
| RLPAXLBK10 |
|
PAXLBK |
|
OPTIONAL
Label Kit Accessory for showing 189
different engineering units FOR Intelligent Panel
Meters |
|
Yes |
|
21,600
|
| |
