| Versatile - Self contained pressure source for calibration of gauges and switches |
|
Features |
- Versatile - Self contained pressure source for calibration of gauges and switches
- Safe - No electrical power or high pressure bottles. Pressure tested to 2x rated pressure
- Accurate — 1/4% full scale with the line of test gauges (optional)
- Adjustable — Precision vernier provides for a wide range of pressure adjustment
- User friendly — Compact size and light weight
- Easier to use — Low handle force at all pressures
- Rugged — “Industrial strength” construction
|
| | | SPECIFICATIONS
|
Model |
TD100 |
TD1000 |
TD2000 |
| Pressure Range |
0-300 psig |
0-300 psig/0-25" Hg Vac |
0-3000 psig |
| Weight |
1.3 lbs. (0.6 kg) |
1.4 lbs. (0.65 kg) |
1.75 lbs (0.79 kg) |
| Dimensions (w/o Test gauge) |
9.5" L x 5" W x 3" D |
10" L x 5" W x 3" D |
11.5" L x 5" W x 3" D |
| Test Connections |
1/4" NPT female |
1/4" NPT female |
1/4" NPT female |
| Materials of Construction |
Machined aluminum body, stainless steel shaft and needle valve, ABS plastic handles, brass connection tee and connector |
| - Hose |
Nylon |
Nylon |
braided metal |
| - Seals |
Viton |
Viton |
Viton |
| Viton is a registered trademark of DuPont Dow Elastomers |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| TD100 |
|
870-300 |
|
0-300 psig Pneumatic Hand Pump (without Test gauge) |
|
Yes |
|
1,026,000 |
| TD2000 |
|
8112-3000 |
|
0-3000 psig Hydraulic Hand Pump (without Test gauge) |
|
Yes |
|
1,630,800 |
| TD1000 |
|
8111-300 |
|
-13.7-300 psig Duplex Hand Pump (without Test gauge) |
|
Yes |
|
1,296,000 |
| D6551415 |
|
65514-15B55 |
|
OPTIONAL -14.7" Hg Vac to 15 PSI Gauge, bottom connection without mounting flange FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,414,800
|
| D6551421 |
|
65514-21B55 |
|
OPTIONAL -14.7" Hg Vac to 30 PSI Gauge, bottom connection without mounting flange FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,414,800
|
| D6551423 |
|
65514-23B55 |
|
OPTIONAL -14.7" Hg Vac to 100 PSI Gauge, bottom connection without mounting flange FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,414,800
|
| D6551426 |
|
65514-26B55 |
|
OPTIONAL -14.7" Hg Vac to 300 PSI Gauge, bottom connection without mounting flange FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,414,800
|
| D6551427 |
|
65514-27B55 |
|
OPTIONAL -14.7" Hg Vac to 500 PSI Gauge, bottom connection without mounting flange FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,630,800
|
| D6551429 |
|
65514-29B55 |
|
OPTIONAL -14.7" Hg Vac to 1000 PSI Gauge, bottom connection without mounting flange, LCD Res: 0.1 FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,630,800
|
| D6551432 |
|
65514-32B55 |
|
OPTIONAL -14.7" Hg Vac to 2000 PSI Gauge, bottom connection without mounting flange, LCD Res: 0.1 FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,630,800
|
| D6551433 |
|
65514-33B55 |
|
OPTIONAL -14.7" Hg Vac to 3000 PSI Gauge, bottom connection without mounting flange, LCD Res: 0.1 FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,630,800
|
| D6551435 |
|
65514-35B55 |
|
OPTIONAL -14.7" Hg Vac to 5000 PSI Gauge, bottom connection without mounting flange, LCD Res: 0.1 FOR Hand Pumps and Digital Test Gauge/Calibrator |
|
Yes |
|
1,725,840
| | |
|
|
 | |
 |
|
 |
|
