| Use the Data Acquisition software to collect and display real time data. |
Use the Data Acquisition software to collect and display real time data. Calculate max/min, average, and standard deviation. Use the buttons on the spreadsheet to operate the gauge from your computer.
DB data buttons work with the software to automate data collection. Enter peak measurements into the spreadsheet and ‘zero’ the gauge with a touch of the button. Minimize computer time and mouse usage. |
| |
|
Features |
- Best value digital force gauge with capacity up to 700 lbs push/pull)
- Accuracy ±0.2% ±1 LSD
- RS-232C, Digimatic and analog outputs
- Overload capacity 200% F.S.
- Ergonomic, heavy-duty metal construction
- lb, kg, and Newtons (selectable)
- Overload alarm, low battery display indicator
- Runs on internal NiCad batteries or AC adapter
- Real time and peak mode (selectable)
- Tare function
- Full set of accessories, AC charger/adapter and carrying case
|
| | |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| IM28427 |
|
DPS-0.5 |
|
8.819 oz/250.0 g/2.452 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28428 |
|
DPS-1 |
|
17.64 oz/500.0 g/4.903 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28429 |
|
DPS-4 |
|
4.409 lb/2.000 kg/19.61 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28430 |
|
DPS-11 |
|
11.02 lb/5.000 kg/49.03 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28431 |
|
DPS-44 |
|
44.09 lb/20.00 kg /196.1 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28432 |
|
DPS-70 |
|
70.2 lb/50.00 kg/490.3 N Capacity Digital Force Guage |
|
Yes |
|
1,285,200 |
| IM28433 |
|
DPS-220 |
|
220.5 lb /100.0 kg/980.6 N Capacity Digital Force Guage |
|
Yes |
|
1,825,200 |
| IM28434 |
|
DPSH-440 |
|
441.0 lb/200.0 kg/1960 N Capacity Digital Force Guage |
|
Yes |
|
2,365,200 |
| IM28435 |
|
DPSH-700 |
|
702 lb/500.0 kg/4900 N Capacity Digital Force Guage |
|
Yes |
|
3,186,000 |
| IM28436 |
|
SW-1 |
|
Data Acquisition Software |
|
Yes |
|
429,840 |
| IM28437 |
|
DB-1 |
|
Data Button |
|
Yes |
|
313,200 |
| IM28438 |
|
CB-203 |
|
RS-232 Cable |
|
Yes |
|
162,000 |
| IM28469 |
|
OH-1 |
|
OPTIONAL Handle FOR Digital Force Gauges |
|
Yes |
|
183,600 |
| |
|
|
 | |
 |
|
 |
|
