| GCL - Gauge Control Language for full control of all functions.RS-232, Mitutoyo and analog outputs |
|
Features |
- RS-232, Mitutoyo and analog outputs
- GCL - Gauge Control Language for full control of all functions
- Programmable analog and digital filters
- General purpose I/O for external device control
- Averaging mode for obtaining average force readings over time
- Programmable initial status of units and mode of operation
- Permanent configuration memory
- Automatic timed output on RS-232
- Dual set points with outputs
- Automatic peak memory
- Push-button calibration
- Battery or AC operation
|
| | | SPECIFICATIONS
|
Accuracy |
±0.2% of full scale ±1 digit |
| Display rate |
2.5-10/sec. 65/sec in peak mode |
| Battery life |
8 -10 hours of continuous use |
| RS-232 |
Fully configurable up to 9600 baud. |
| Includes GCL - Gauge Control Language |
| Set point outputs |
Three open collector lines (utilizing Mitutoyo lines) |
| Sensor deflection |
0.010 [0.25 mm] maximum deflection at full load |
| Weight (gauge only) |
0.95 lb [0.4 kg] |
| Analog output |
±1 VDC ±0.25% of full scale at capacity. Positive for compression, negative for tension |
| Sampling rate |
65 readings per second |
| Display |
4fi-digit LCD 0.3" [7.6 mm] high. Indicators for low battery, units and mode of operation |
| Power |
AC or rechargeable battery with IPM, a 3-step Intelligent Power Management system that warns the user via "LO BAT" indicator and then will shut off the gauge |
| Mitutoyo output |
Serial BCD suitable for all Mitutoyo SPC-compatible devices. |
| General purpose I/O |
Three open collector outputs and one input (utilizing Mitutoyo lines) |
| Safe overload |
150% of full range. Display shows "----" at 70% and above |
| Included accessories |
Chisel, cone, V-groove, hook, flat, extension |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| MK21171 |
|
BG025 |
|
0.25 x 0.0001 lb Digital Force Gauge |
|
Yes |
|
2,581,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK21172 |
|
BG05 |
|
0.5 x 0.0002 lb Digital Force Gauge |
|
Yes |
|
2,581,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2118 |
|
BG2 |
|
2 x 0.001 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2117 |
|
BG5 |
|
5 x 0.002 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2119 |
|
BG10 |
|
10 x 0.005 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2122 |
|
BG20 |
|
20 x 0.01 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2120 |
|
BG50 |
|
50 x 0.02 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2121 |
|
BG100 |
|
100 x 0.05 lb Digital Force Gauge |
|
Yes |
|
2,149,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK21311 |
|
BG200 |
|
200 x 0.1 lb Digital Force Gauge |
|
Yes |
|
|
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. |
| MK2123 |
|
BG500 |
|
500 x 0.2 lb Digital Force Gauge |
|
Yes |
|
2,473,200 |
| Gauge comes supplied in a cushioned carrying case with an AC adapter, user's manual, and a set of accessories as listed in the table above. | | |
|
|
 | |
 |
|
 |
|
