| Stores 20 readings in memory.Measure positive, negative or differential pressures |
|
Features |
- Stores 20 readings in memory
- Measure positive, negative or differential pressures
- Large, easy-to-read 0.4" LCD display
- Includes switchable backlight for great visibility
- Both audible and visual overpressure alarms
- Includes + and - indicators plus low battery warning
- Operates up to 100 hours on a single volt battery
- Pressure units available
|
| | | PRESSURE UNITS AVAILABLE
Model
Number |
PSID |
in.
H2O |
mm
H2O |
in.
Hg |
mm
Hg |
Pa
|
kPa
|
bar
|
Mbar
|
| DW400 |
• |
• |
• |
• |
• |
• |
• |
• |
• |
| DW401 |
• |
• |
• |
• |
• |
• |
• |
• |
• |
| DW402 |
• |
• |
• |
• |
• |
|
• |
• |
• |
| DW403 |
• |
• |
• |
• |
• |
|
• |
• |
• |
| DW404 |
• |
• |
|
• |
• |
|
• |
• |
• |
SPECIFICATIONS
|
Accuracy |
±0.5% of full scale from 60 to 78°F (15 to 25°C) |
| ±1% of full scale from 78 to 104°F (0 to 15, 25 to 40°C) |
| Pressure Hysteresis |
±0.1% of full scale |
| Pressure Connections |
Barbed, for 1/8" or 3/16" I.D. tubing |
| Power Source |
9V alkaline battery, included |
| Battery Life |
Up to 100 hours of operation, Less when LCD backlight is used |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| DW400 |
|
477-1-FM |
|
HANDHELD DIGITAL MANOMETER 0-20 in W.C. |
|
Yes |
|
766,800 |
| DW401 |
|
477-2-FM |
|
HANDHELD DIGITAL MANOMETER 0-40 in WC |
|
Yes |
|
766,800 |
| DW402 |
|
477-3-FM |
|
HANDHELD DIGITAL MANOMETER 0-200 in WC |
|
Yes |
|
766,800 |
| DW403 |
|
477-4 |
|
HANDHELD DIGITAL MANOMETER 0-10 psid |
|
Yes |
|
766,800 |
| DW404 |
|
477-5 |
|
HANDHELD DIGITAL MANOMETER 0-30 psid |
|
Yes |
|
766,800 |
| DW405 |
|
A-402 |
|
OPTIONAL CARRYING POUCH FOR HANDHELD DIGITAL MANOMETER FOR Intrinsically Safe Handheld Digital Manometer |
|
Yes |
|
55,620
| | |
|
|
 | |
 |
|
 |
|
