SPECIFICATIONS FOR AM5741
| Thermocople Ranges |
B, C, E, J, K, L, N, R, S, T, U, XK |
| RTD Ranges |
Pt100, Pt200, Pt500, PT1000, Ni120, Pt3916, Pt3926, Cu10, YSI400, Pt10, PT50 and Cu100 |
| Ohms Ranges (Source) |
5.0 to 400.0 ohms, 400 to 4000 ohms |
| Accuracy |
Ranges from 0.1 to 1 ohm |
| Ohms Ranges (Read) |
5.00 to 400.00 ohns, 400.0 to 4000.0 ohms |
| Accuracy |
Ranges from 0.1 to 1 ohm |
| mV Ranges |
-10.00 to 75.00mV |
| Accuracy |
±0.02T of reading ±20uV |
| CJC Control |
Yes |
| Thermocouple Accuracy |
0.4 °C typical at 0.0 °C J type |
| RTD Accuracy |
0.2 °C typical on Pt100 range |
| RTD IEX Range |
0.01mA to 3mA |
| Stability |
±0.005% FS/C (<18°C or >28°C) |
| Power Supply |
1 9V battery |
| AM5741 Delivery |
Calibrator - Test Leads - Soft Carrying Case - Shoulder Strap - Operating Manual - NIST Traceable Certificate |
| CAT NO. |
 |
MODEL |
|
DEscRIPTION |
|
AVAIL |
|
PRICE |
| AM5741 |
|
CSC200G |
|
Thermocouple Calibrator |
|
Yes |
|
2,377,620 |
| |
|
|
 | |
 |
|
 |
|
